北京龙天韬略科技有限公司专业提供德国耶拿TOC耗材配件，产品货号如下：
analytikjena
Consumables
multi N/C series
effective from 01.01.2010
Priority Order number Description
ConSUMABLES TOC
(all types of instruments)
A 402-810.047 Special catalyst multi N/C, one filling, 40 g
recommended for multi N/C 3000/3100
A 402-810.048 Special catalyst platinum, one refill
multi N/C 2100: recommended for multi N/C 2000/2100/2100 S multi N/C 2100 S: recommended for multi N/C 2000/2100/2100 S
A 402-810.050 Halogen absorber filling (copper- and brass wool)
B 402-810.058 Special catalyst multi N/C, 200 g
recommended for multi N/C 3000/3100
B 402-810.059 Special catalyst platinum, sufficient for 5 refills
multi N/C 2100: recommended for multi N/C 2000/2100/2100 S multi N/C 2100 S: recommended for multi N/C 2000/2100/2100 S
A 402-825.044 Quartz wool, 1 packet
A 402-825.150 U-tube, o.d. = 11 mm, without filling for halogenabsorber
(without connections)
A 402-881.006 Quartz glass cullet, coarse grains, packet of 80 g
A 402-881.228 Disposable retention filter (water trap) A 402-881.229 TC prefilter (aerosol trap)
402-881.245 Set of TC prefilter and water trap
A 402-885.017 High-temperature mat, set of 3 pieces
B 402-885.019 Halogen absorber, complete with U-tube
multi N/C 2100 and multi N/C 2100 S multi N/C 2100 WEARING MATERIAL
B 402-000.008 Stirring magnets, 15 mm x 6 mm, 10 pieces
A 402-520.137 Glass screw joint (gray)
A 402-815.058 Lab-type screw joint D 3.2 - GL 14, complete (red)
A 402-815.102 O-rings for combustion tube, set of 3 pieces
B 402-815.138 Dosing syringe for phosphoric acid, 5 ml
402-815.819 O-ring; 15.5 mm x 2.5 mm; Viton IC-vessel N/C 2100 S (Stopper)
A 402-823.056 Needle; 0.63 mm x 0.35 mm; for all types of syringes; set of 3 pieces
A 402-825.041 Fork-type clamp KS 13/2 with clamping screw
A 402-881.026 Finger-Tight-Set 1/8" for tube set, PEEK
A 402-881.027 Finger-Tight-Set 1/16" for tube set, PEEK
A 402-881.238 Septa for pneumatic heads, 10 mm o.d., set of 10 pieces
multi N/C 2100: only for N/C 2100 S
A 402-884.005 Pump hose for peristaltic pump, waste
A 402-885.010 Combustion tube
B 402-886.303 Syringe 100 µl with vent and removable needle 0.63 mm x
0.35 mm (only for APG 60)
B 402-886.304 Syringe 250 µl with vent and removable needle 1 mm x 0.7 mm (only for APG 60)
A 402-886.305 Syringe 500 µl with vent and removable needle 1 mm x 0.7
A 402-885.011 Pump hose for H3PO4 pump mm (only for APG 60) 
A 402-886.306 Needle 1 mm x 0.7 mm; for all types of syringes, 3 pieces
multi N/C 2100: only for multi N/C 2100 S
A 402-886.310 Septum for syringe (autosampler); 9.5 mm o.d.; 1 piece
B 402-886.311 Syringe graduated 500 µl with removable needle for manual injection
A 402-886.314 Septa pre-cut for septum-head, 11 mm, 3 pieces
A 402-886.317 Condensing loop multi N/C 2000/2100/2100 S
B 402-886.318 Sample vials, 8 ml
50 mm x 18 mm, 125 pieces multi N/C 2100: for APG 60-sampler multi N/C 2100 S: for APG 60-sampler
A 402-889.050 Septum; 12.5 mm; set of 5 pieces
multi N/C 2100: for manual TIC - Port multi N/C 3100: for POC Modul
B 402-889.091 Lids for sample vials, 2 ml, set of 500 pieces
B 402-889.092 Sample vials, 2 ml, set of 100 pieces
(for sample rack with 112 positions)
402-890.100 IC condensing vessel multi N/C 2100
A 402-890.110 tubing kit for multi N/C 2100 S
A 402-890.111 tubing kit for multi N/C 2100
B 402-890.113 needle with luer connector for H3PO4-syringe 402-890.150 IC condensing vessel multi N/C 2100 S
WEARING MATERIAL Double Furnace Solids Module
402-889.674 Quartz boat, 40 mm x 9 mm, set of 10 pieces
A 402-890.103 Furnace sealing plug
A 402-890.104 Solid combustion tube
A 402-890.105 Hook
A 402-890.106 Guidance tube
402-890.107 Gasket for oxygen lock
A 402-890.108 Gas transfer tubing, adapter with ball joint
A 402-890.109 O2 tubing
multi N/C 3100 multi N/C 3100 WEARING MATERIAL
B 402-000.005 Sample vials, 80 mm x 33 mm, 70 pieces
multi N/C 3100: for dilution rack APG 64
B 402-000.008 Stirring magnets, 15 mm x 6 mm, 10 pieces
A 402-520.135 Fork-type clamp for oxygen supply
A 402-520.137 Glass screw joint (gray)
A 402-815.058 Lab-type screw joint D 3.2 - GL 14, complete (red)
A 402-815.102 O-rings for combustion tube, set of 3 pieces
B 402-815.204 Septum silicon/PTFE, 24 mm, for screw cap EPA, set of
100 pieces
B 402-815.205 Screw cap for 40 ml EPA screw thread vial, set of 100 pieces
B 402-820.075 Bottle Insert
402-825.041 Fork-type clamp KS 13/2 with clamping screw
B 402-825.099 Sample vials for dilution rack, 100 mm x 16 mm, 10 pieces
B 402-825.119 Sample vessels for EPA Sampler with piercing function, set of 100 pieces
40 ml EPA screw thread vial
A 402-881.026 Finger-Tight-Set 1/8" for tube set, PEEK
A 402-881.027 Finger-Tight-Set 1/16" for tube set, PEEK
B 402-883.005 Sample aspiration
multi N/C 3100: also purge tube
A 402-884.005 Pump hose for peristaltic pump, waste
A 402-884.019 Injection tube
B 402-884.021 Waste hose with screw joint (2 m)
B 402-884.023 Lid for Bottle Insert 402-885.002 Condensation coil
A 402-885.010 Combustion tube
A 402-885.011 Pump hose for H3PO4 pump
A 402-885.016 Sample aspiration tube with screw joint
multi N/C 3100: also purge tube
B 402-886.319 Sample vials for APG 64-sampler, 78 mm x 28 mm, 100 pieces
A 402-889.050 Septum; 12.5 mm; set of 5 pieces
multi N/C 2100: for manual TIC - Port multi N/C 3100: for POC Modul
402-890.163 Piercing sample aspiration tube for EPA sampler, titanium
402-890.164 Piercing sample purge tube for EPA sampler, titanium
402-890.193 Tubing kit for multi N/C 3100
402-890.200 Condensation vessel
HT 1300
HT 1300 WEARING MATERIAL
402-815.830 Gasket for dust trap for HT furnace (34 mm x 4 mm)
A 402-825.044 Quartz wool, 1 packet
A 402-881.013 U-tube, o.d. = 21 mm for halogen absorber
A 402-881.203 Glass tube, straight, without connectors
A 402-881.213 Headline-Disposable-In-Line-Filter, box of 10 pieces
B 402-886.001 Ceran field for HT furnace
B 402-886.003 Connecting hose "Analyt" for HT furnace, 4 mm x 6 mm, 1 m long
B 402-886.004 Connecting hose "pump" for HT furnace, 4 mm x 6 mm, 1 m long
A 402-886.005 Connecting hose "oxygen supply" for HT furnace, 4 mm x
6 mm, 2 m long
B 402-886.006 Feeding tool for HT furnace
A 402-886.014 Ceramic combustion tube
B 402-886.114 Halogen absorber filling for straight tube A 402-886.116 Drying agent
A 402-886.118 Porcelain boat (white); 1,000 pieces
A 402-886.312 Halogen absorber filling for U-tube, o.d. = 21 mm
(conditioned)
402-886.322 Halogen absorber filling (conditioned)
for U-tube, o.d. = 21 mm, set of 5 pieces
Warranty claims and claims related to the fulfillment of manufacture's technical specification can only be accepted by using original Analytik Jena components, spares and consumables.
Specifications and order numbers are subject to changes due to further technical development.
Prices are quoted exclusive of value added tax.
Purchase is subject to the General Terms and Conditions of Analytik Jena AG.
